Vibrator Motor
Vibrator Motor 0.00৳

Induction Motor

Original price was: 53,500.00৳ .Current price is: 46,500.00৳ .

Overview

AC Induction Motor range includes General Purpose motors, Crane & Hoist application motors, brake motors, Inverter duty motors, cooling tower motors, Premium efficiency IE2 & IE3 motors and customized motors.

AC ASYNCHRONOUS ELECTRIC MOTOR # 15 kw

About ELECTRIC MOTORS

We can also provide customers with matching high-performance motors to better match our VFD products.

Advantages

The advantages of asynchronous motor include the following:

1) Less cost

2) Easy to maintain

3) Efficiency is high in partial-load operation

4) Appropriate for high revolving speeds, which permits high o/ps to be attained also.

Color

Blue, Pink
Compare
Add to wishlist
Categories: , Tag:
Description

Overview:

AC ASYNCHRONOUS ELECTRIC MOTOR

AC Induction Motor range includes General Purpose motors, Crane & Hoist application motors, brake motors, Inverter duty motors, cooling tower motors, Premium efficiency IE2 & IE3 motors and customized motors.

Applications

Most of the motors used in different applications in the world are asynchronous. The applications mainly include the following.

1) Centrifugal Pumps

2) Blowers

3) Fans

4) Conveyors

5) Compressors

6) Heavy Duty Cranes

7) Lifts

8) Lathe Machines

9) Paper Mills

10) Oil Mills

11) Textiles

Model (China)   Rated Power Rated Voltage   No-load Speed
(Rpm)		 Rated   Torque
(N.m)
YE3-80M1-2 0.75KW 380V 1452 2.54
YE3-80M2-4 0.75KW 380V 1452 2.55
YE3-90S-4 1.1kW 380V 1452 7.5
YE3-80M2-2 1.1kW 380V 1452 3.72
YE3-90L-4 1.5kW 380V 1452 10.2
YE3-100L-6 1.5kW 380V 1452 15.4
YE3-90S-2 1.5kW 380V 1452 5.04
YE3-112M-4 4KW 380V 1452 20,2
YE3-112M-2 4KW 380V 1452 13.3
YE3-132M1-6 4KW 380V 1452 39.8
YE3-132S-4 5.5KW 380V 1452 36.5
YE3-132S1-2 5.5KW 380V 1452 18.1
YE3-132M2-6 5.5KW 380V 1452 54.7
YE3-132M-4 7.5KW 380V 1452 49.7
YE3-132S2-2 7.5KW 380V 1452 24.7
YE3-160M-4 11KW 380V 1452 72
YE3-160L-4 15KW 380V 1452 98.1
YE3-180M-4 18.5KW 380V 1452 120.6
YE3-180L-4 22KW 380V 1452 143.4
YE3-200L-4 30KW 380V 1452 194.9
YE3-225S-4 37KW 380V 1452 239.6
YE3-225M-4 45KW 380V 1452 291.4
6W Fixed Speed Motor 6W 220V/380V 1440 0.045
15W Fixed Speed Motor 15W 220V/380V 1440 0.12
25W Fixed Speed Motor 25W 220V/380V 1440 0.2
40W Fixed Speed Motor 40W 220V/380V 1440 0.3
60W Fixed Speed Motor 60W 220V/380V 1440 0.45
90W Fixed Speed Motor 90W 220V/380V 1440 0.67
120W Fixed Speed Motor 120W 220V/380V 1440 0.8
140W Optical Axis Motor 140W 220V/380V 1440 1.15
160W Fixed Speed Motor 160W 220V/380V 1440 1.26
180W Fixed Speed Motor 180W 220V/380V 1440 1.3
200W Fixed Speed Motor 200W 220V/380V 1440 1.47
250W Fixed Speed Motor 250W 220V/380V 1440 1.79
Additional Brake 6W-250W 220V/380V 1440 2



If required please contact us for details



Thanks

CEO (Sales & Marketing)

Z3 Automation Engineering

Address: 476/C/1, DIT Road, Dhaka-1219.

E-Mail: info@z3automation.com

Website: www.z3automaion.com

What’s App: +880 1716 267283

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Induction Motor”
